• -4AN PTFE braided turbo oil feed line – standard length 35 cm
• Precision turbo oil inlet fitting – non-restricted -4AN to 1/8" NPT
• Engine-side oil port banjo bolt with -4AN connection
• Copper sealing washers
• AVCS T-fitting and secondary oil line – AVCS option only
Subaru EJ20 EJ25 Rotated Precision PTE Turbo Oil Feed Line Kit
Subaru EJ20 EJ25 Rotated Precision PTE Turbo Oil Feed Line Kit
Regular price
$99.87 USD
Regular price
$0.00 USD
Sale price
$99.87 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
No PayPal Account Required
We accept Visa, Mastercard, Amex, JCB
Click PayPal, then select "Pay with a Card"
Worldwide
DHL, FEDEX, EMSFast Ship
48H DispatchFree Ship
AU/US & MoreTailored
Customizable30-Day
ReturnsSecured
SSL Encrypted
Technical Description
This turbo oil feed line kit is designed for turbocharged Subaru EJ20 and EJ25 engines using supported rotated-mount Precision Turbo (PTE) 5858, 6262, 6266, 6466, 6766 or 6870 turbochargers. It connects the applicable Subaru engine oil supply to the Precision turbo oil inlet using a flexible -4AN PTFE braided line and a non-restricted turbo-side fitting.
A rotated turbo installation relocates the turbocharger away from the original stock position, making the factory rigid oil feed routing unsuitable. The standard oil feed line length is 35 cm, with custom lengths available for installations using different turbo positions, up-pipes or intake manifold layouts.
Choose the Correct Engine Configuration
- Non-AVCS: For engines using the corresponding direct turbo oil feed arrangement.
- AVCS: Includes the required T-fitting and secondary oil line for the applicable AVCS oil feed layout.
Important: AVCS equipment varies by engine code, model year, market and engine conversion history. Select the configuration by inspecting the installed engine-side oil routing rather than relying on EJ20 or EJ25 displacement alone.
Key Features
- Designed for supported Subaru EJ20 and EJ25 rotated Precision PTE installations
- -4AN PTFE oil feed line with a 304 stainless steel outer braid
- Non-restricted Precision turbo oil inlet fitting
- Available with AVCS or Non-AVCS engine-side connection hardware
Installation Notes
Measure the required hose route before ordering, especially when the turbo position, up-pipe or intake configuration differs from a typical rotated installation. Custom line lengths should be confirmed before purchase.
Inspect and clean the engine oil supply path before installation. Route the braided line away from exhaust components, sharp edges and moving parts. Prime the turbo and oil feed line before the first engine start, then inspect every connection for leaks after the engine reaches operating temperature.
This product covers the turbo oil feed side only. It does not include an oil drain pipe or return hose and is not designed for stock-location TD04, TD05H, IHI VF-Series or Garrett GT28R / GT30R installations.
Need help confirming your engine and turbo configuration? View the Subaru EJ20 / EJ25 Turbo Oil Line Fitment Guide.
